如何使安卓app适配全面屏手机实现完全全屏显示

发表于 更新于
作者 Zpekii
2 分钟阅读

安卓app实现全面屏显示

主要修改类文件MainActivity.java

重写类方法onCreate

适配全面屏显示，消除letterbox黑边

  • 在onCreate方法下编写以下内容，设置app显示布局模式layoutInDisplayCutoutMode,官方详细描述:https://developer.android.com/develop/ui/views/layout/display-cutout?hl=zh-cn#handle

  • 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18


import androidx.appcompat.app.AppCompatActivity;

public class MainActivity extends AppCompatActivity{

    @override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        getWindow().addFlags(WindowManager.LayoutParams.FLAG_TRANSLUCENT_STATUS);

        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.P) {
            getWindow().getAttributes().layoutInDisplayCutoutMode = WindowManager.LayoutParams.LAYOUT_IN_DISPLAY_CUTOUT_MODE_ALWAYS;
        }

	}
}

隐藏系统UI

  • 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

    @RequiresApi(api = Build.VERSION_CODES.R)
private void hideSystemUI() {
        // 获取当前窗口的装饰视图
        View decorView = getWindow().getDecorView();

        // 获取 WindowInsetsController
        WindowInsetsController insetsController = decorView.getWindowInsetsController();
        if (insetsController != null) {
            // 设置系统 UI 行为: 可以通过滑动调出系统UI，短暂显示系统UI
            insetsController.setSystemBarsBehavior(WindowInsetsController.BEHAVIOR_SHOW_TRANSIENT_BARS_BY_SWIPE);

            // 隐藏手势条
            insetsController.hide((WindowInsets.Type.systemGestures()));

            // 隐藏系统栏：状态栏、导航栏
            insetsController.hide((WindowInsets.Type.systemBars()));

        }
}

设置默认翻转显示

  • 1

    setRequestedOrientation(ActivityInfo.SCREEN_ORIENTATION_SENSOR_LANDSCAPE);

完整示例

  • 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46

    import androidx.appcompat.app.AppCompatActivity;
import android.view.View;
import android.view.WindowManager;
import android.content.pm.ActivityInfo;

public class MainActivity extends AppCompatActivity{

    @override
    protected void onCreate(Bundle savedInstanceState) {
        super.onCreate(savedInstanceState);

        getWindow().addFlags(WindowManager.LayoutParams.FLAG_TRANSLUCENT_STATUS);

        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.P) {
            getWindow().getAttributes().layoutInDisplayCutoutMode = WindowManager.LayoutParams.LAYOUT_IN_DISPLAY_CUTOUT_MODE_ALWAYS;
        }

		setRequestedOrientation(ActivityInfo.SCREEN_ORIENTATION_SENSOR_LANDSCAPE);

    	// 隐藏系统 UI
        if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.R) {
            hideSystemUI();
        }

    }

     @RequiresApi(api = Build.VERSION_CODES.R)
	private void hideSystemUI() {
        // 获取当前窗口的装饰视图
        View decorView = getWindow().getDecorView();

        // 获取 WindowInsetsController
        WindowInsetsController insetsController = decorView.getWindowInsetsController();
        if (insetsController != null) {
            // 设置系统 UI 行为: 可以通过滑动调出系统UI，短暂显示系统UI
            insetsController.setSystemBarsBehavior(WindowInsetsController.BEHAVIOR_SHOW_TRANSIENT_BARS_BY_SWIPE);

            // 隐藏手势条
            insetsController.hide((WindowInsets.Type.systemGestures()));

            // 隐藏系统栏：状态栏、导航栏
            insetsController.hide((WindowInsets.Type.systemBars()));

        }
    }
}

参考

stackoverflow:android - Fullscreen App With DisplayCutout - Stack Overflow

安卓文档:

android
android
本文由作者按照 CC BY 4.0 进行授权
